Drain Field Repair & Replacement · Loganville, GA
Drain field repair and replacement in Loganville, Georgia, fitting new trench into the soil and setbacks that Walton or Gwinnett health officials will approve.
- Georgia DPH-certified installer & pumper
- Residential & commercial
- Local shop in Oxford, GA
Get a free estimate
or call (678) 863-5620The short answer
How is a drain field repaired in Loganville, GA?
Drain field repair in Loganville is permitted work. On the Walton side it runs on a $200 repair permit, with a Level III soil report if new trench is added; on the Gwinnett side GNR requires a Level 3 soil report for any repair. New lines must stay 100 feet from wells, and sewer availability is checked first.↗↗↗↗
Reviewed by Atlanta Water & Sewage Solutions · Last updated
The Loganville story
Why Loganville fields quit early
Across Walton County, not one acre of mapped soil earns a clean bill for septic absorption. The NRCS survey rates about 159,000 acres somewhat limited and roughly 46,000 acres, a bit over a fifth of the county, very limited. There is no not-limited class at all.↗
That matters on subdivision lots cut in the 2000s. Grading strips topsoil, heavy equipment compacts what is left, and the trenches end up bearing down on dense clay. NC State Extension notes that clogging happens in the first few inches of soil under the trench bottom, so a field on compacted ground can seal within a couple of decades.↗
Before condemning a field, we pump the tank and check the tees and distribution box. A tipped box or missing outlet tee can drown one trench while the others sit dry, and that is a much smaller repair.
On the record
- Walton soils rated for septic absorption fields: about 159,283 acres somewhat limited, 46,045 acres very limited (~22%), none rated not limited.↗
More about Loganville
Repair it, or connect to city sewer?
Inside the limits, ask this before any digging. Loganville bars septic where sewer is available and makes every structure connect when it is. A dead field on a street with a city main may be the push to tie in rather than rebuild.↗
Treated city wastewater leaves the plant on Highway 81 North for Big Flat Creek, and Walton's lot ordinance will not count ground within 50 feet of a stream toward a septic field. Lots that back onto a creek branch have less room for a replacement than their acreage suggests.↗↗
Inside the limits, ask this before any digging.
Local facts
Setbacks that decide where trench can go
Each row links to the agency, code or publisher it comes from. Tap a source to check it yourself.
| Topic | What it says | Source |
|---|---|---|
| Wells, springs, sinkholes | 100 feet | Ga. Comp. R. & Regs. 511-3-1-.07(3) setbacks |
| Water supply lines, basement walls | 10 feet; a water line that must cross goes at least 12 inches above the aggregate, sleeved | Ga. Comp. R. & Regs. 511-3-1-.07(3) setbacks |
| Property lines, drives, slab houses | 5 feet | Ga. Comp. R. & Regs. 511-3-1-.07(3) setbacks |
| Pool foundations, embankments, ditches | 15 feet | Ga. Comp. R. & Regs. 511-3-1-.07(3) setbacks |
Permits · Walton County Environmental Health (NEHD) or GNR Health (Gwinnett side)
Permitting the repair
- 01
Walton: a repair permit and a specialist's inspection before backfill, as for any system repair.↗
- 02
Walton: extra trench counts as an addition, which brings a Level III soil report and a $200 final inspection.↗
- 03
Gwinnett: a Level 3 soil report comes with every septic permit, repairs included.↗
- 04
Gwinnett: when the county opens the file because of a complaint, the residential site evaluation, permit and inspection fee rises to $400.↗
Warning signs
Field symptoms we see around Loganville
Seeing two or more of these? Call before it gets worse.
- 1. Stripes of lush grass tracing the trench lines
- 2. Soggy ground downhill of the field days after rain
- 3. Toilets slow only after laundry or a houseful of guests
- 4. Sewage smell over the yard rather than at the tank
- 5. Effluent surfacing near a neighbor's fence line
What it costs
Field repair and replacement ranges
Drain field repair or rejuvenation
$1,000–$5,000
Typical market range — HomeGuide — How Much Does a Leach or Drain Field Replacement Cost? (2026), 2026
Drain field replacement
$3,000–$15,000
Typical market range — HomeGuide — How Much Does a Leach or Drain Field Replacement Cost? (2026), 2026
Relocate a leach field
$5,500–$21,500
Typical market range — HomeGuide — How Much Does a Leach or Drain Field Replacement Cost? (2026), 2026
Replace leach lines
$20–$45 per linear foot
Typical market range — HomeGuide — How Much Does a Leach or Drain Field Replacement Cost? (2026), 2026
Field line cleaning
$600–$1,100
Typical market range — Angi — How Much Does It Cost to Clean Septic Field Lines? (updated Jul 9, 2026), 2026
What moves the price
These are third-party typical market ranges, not our prices. Every job is quoted after we see it — estimates are free.
Free estimate: (678) 863-5620- 01Walton or Gwinnett, and whether a soil classifier must be hired
- 02Room left after a pool, shed or driveway took part of the yard
- 03Distance from a private well
- 04Slope that forces trench on contour or a pump to reach good soil
More about Loganville
Residential yards and commercial lots
Most of our Loganville field jobs are single-family. A business on its own system pays Walton's $365 commercial repair permit, and parking and truck traffic over the field are the usual culprits, so the fix often includes moving the field out from under the pavement.↗
State-certified installer
Check the roster before anyone digs: our company is on DPH's certified installer list dated 9/18/2026, under Walton County.
FAQ
Loganville drain field questions
Straight answers, with the rule or record behind them. Still unsure? Call and ask the crew that digs.
(678) 863-5620Can a failing Loganville drain field be saved?
Sometimes. If the trenches are not fully sealed and the cause upstream is fixed, partial rebuilding works. NC State notes a completely clogged soil usually needs a new field.
Source: NC State Extension — Septic Systems and Their Maintenance
Does adding trench need a soil report on the Walton side?
Yes. Walton treats added trench as an addition: Level III soil report and a $200 final inspection.
Source: Walton County Environmental Health — Service Request Form
How close can a new field be to my well?
No closer than 100 feet under Georgia's setback rule. On a one-acre lot that often decides where the field goes.
A neighbor complained. Does that change the Gwinnett fee?
It can. GNR's schedule lists $400 for a residential site evaluation, permit and inspection that starts from a complaint, versus $275 otherwise.
Source: GNR Environmental Health Fee Schedule — Gwinnett County (Rev. 08/26/25, adopted Aug 25, 2025)
Is the soil around Loganville bad for septic?
It is slow. NRCS rates every mapped Walton soil at least somewhat limited for absorption fields, and about 22 percent very limited.
Should I connect to city sewer instead of rebuilding?
If a main is available, the city requires it. Ask Loganville's utility department; it determines availability.
Source: City of Loganville Development Regulations (adopted 2020, amended Aug 8, 2024)
Sources
Where these facts come from
Rules, costs and local facts on this page link to the agency, code or publisher that states them. Cost figures are third-party market ranges, not our prices — estimates are free.
Reviewed by Atlanta Water & Sewage Solutions · Last updated
- 1Walton County EH Fees (effective August 1, 2024)
- 2Walton County Environmental Health — Service Request Form
- 3Septic Systems | GNR Health
- 4Ga. Comp. R. & Regs. 511-3-1-.07(3) setbacks
- 5USDA NRCS Soil Data Access — GA297 (Walton County), ENG - Septic Tank Absorption Fields interpretation
- 6NC State Extension — Septic Systems and Their Maintenance
- 7City of Loganville Development Regulations (adopted 2020, amended Aug 8, 2024)
- 8Wastewater Treatment Facility | City of Loganville, GA
- 9Walton County Board of Health — Minimum Lot Size Ordinance
- 10Northeast Health District — Sewage/Septic Systems
- 11GNR Environmental Health Fee Schedule — Gwinnett County (Rev. 08/26/25, adopted Aug 25, 2025)
- 12HomeGuide — How Much Does a Leach or Drain Field Replacement Cost? (2026)
- 13Angi — How Much Does It Cost to Clean Septic Field Lines? (updated Jul 9, 2026)
- 14Georgia DPH — Certified Septic Tank Installers list (9/18/2026)
